Jensen HDS3000 Surface-Mount Speaker Replacement
The Jensen HDS3000 heavy-duty surface-mount speakers have been discontinued and are no longer available from Heavy Duty Radios. The REI 760663 speaker pair is our recommended current alternative for customers who need rugged, enclosed 5-inch speakers that can be installed without cutting large speaker openings.
Also available from our sister site, Farm Radio Supply.
REI 760663 - $68.99
CURRENT REPLACEMENT
CURRENT REPLACEMENT
Jensen HDS3000
DISCONTINUED
DISCONTINUED
Why Replace the HDS3000 With the REI 760663?
The REI 760663 is a strong current alternative to the discontinued Jensen HDS3000. Both products provide enclosed 5-inch speakers that mount on a surface, eliminating the need to cut large openings for conventional flush-mount speakers.
The REI enclosure is more compact and easier to position in equipment where available space is limited. Its adjustable mounting design allows each speaker to be aimed toward the operator for better sound inside a noisy cab.
The REI enclosure is more compact and easier to position in equipment where available space is limited. Its adjustable mounting design allows each speaker to be aimed toward the operator for better sound inside a noisy cab.
Important Replacement Differences
The REI 760663 is a recommended alternative, but it is not an identical bolt-for-bolt replacement for the HDS3000. Before ordering, compare the available mounting area and bracket-hole locations.
The existing speaker wires can normally be reused when they are in good condition, but the wire ends or connectors may need to be adapted. Both speaker systems use a standard 4-ohm configuration and are sold as a pair.
The existing speaker wires can normally be reused when they are in good condition, but the wire ends or connectors may need to be adapted. Both speaker systems use a standard 4-ohm configuration and are sold as a pair.
HDS3000 and REI 760663 Comparison
| Feature | Jensen HDS3000 | REI 760663 |
|---|---|---|
| Availability | Discontinued | Current Replacement |
| Speaker Size | 5-inch | 5-inch |
| Enclosure Style | Surface mount | Surface mount |
| Approximate Size | 6.69 × 4.76 × 4.43 inches | 5.42 × 5.42 × 4.3 inches |
| Impedance | 4 ohms | 4 ohms |
| Quantity | Sold as a pair | Sold as a pair |
| Large Cutout Required | No | No |
| Direct Bolt-In Replacement | Original product | No—check mounting space |
Why Choose Enclosed Surface-Mount Speakers?
Surface-mount speakers are an excellent choice when cutting a large speaker opening is difficult or undesirable. The complete speaker enclosure mounts to a solid surface and can be positioned toward the operator.
This makes the REI 760663 suitable for equipment cabs, overhead panels, sidewalls and other locations where conventional flush-mount speakers will not fit. The enclosed design also provides a finished installation without requiring the equipment panel to serve as the speaker enclosure.
This makes the REI 760663 suitable for equipment cabs, overhead panels, sidewalls and other locations where conventional flush-mount speakers will not fit. The enclosed design also provides a finished installation without requiring the equipment panel to serve as the speaker enclosure.
Good Applications for the REI 760663
- Tractors
- Skid steers
- Excavators
- Loaders
- Graders
- Utility vehicles
- Commercial vehicles
- Construction equipment
- Agricultural equipment
- Equipment cabs and overhead panels
Before Ordering
Measure the available mounting area before ordering. Each REI 760663 enclosure measures approximately 5.42 inches wide, 5.42 inches high and 4.3 inches deep.
Confirm that the mounting surface is solid, that the speakers can be aimed toward the operator and that there is enough clearance for the brackets and wiring. Do not assume the HDS3000 mounting holes will align with the REI 760663 brackets.
Confirm that the mounting surface is solid, that the speakers can be aimed toward the operator and that there is enough clearance for the brackets and wiring. Do not assume the HDS3000 mounting holes will align with the REI 760663 brackets.
Installation Guidance
Mount each speaker bracket to a solid surface using hardware appropriate for the material and application. Position the speakers where the grilles will not be blocked and aim them toward the normal operating position.
Connect the speakers to the radio’s left and right speaker outputs while maintaining correct polarity. Avoid mounting the speakers where controls, visibility, doors or protective equipment could be obstructed.
Connect the speakers to the radio’s left and right speaker outputs while maintaining correct polarity. Avoid mounting the speakers where controls, visibility, doors or protective equipment could be obstructed.
Frequently Asked Questions
Is the Jensen HDS3000 still available?
No. The Jensen HDS3000 speaker pair has been discontinued and is no longer available from Heavy Duty Radios.
Is the REI 760663 a direct replacement?
The REI 760663 is a recommended functional alternative, but it is not guaranteed to use the same mounting holes. Compare the enclosure dimensions and bracket locations before ordering.
Are the REI 760663 speakers sold individually?
No. The REI 760663 speakers are sold as a complete pair.
Will I need to cut large speaker openings?
No. These are enclosed surface-mount speakers. Only the mounting hardware and speaker-wire routing are normally required.
Can I reuse the original speaker wiring?
Existing speaker wiring can usually be reused when it is correctly installed and remains in good condition. The wire ends or connectors may need to be changed for the new speakers.
